5.1 lbs

CPU Compatibility

Intel Socket LGA 1851, 1700, 1200, 115X, 2011*, 2066* – AMD Socket AM5, AM4, TR4* – *Optional brackets, please contact support

Heat Exchanger Dimensions

120 x 288 x 52 mm

Heat Exchanger Material

Aluminum

Heat Exchanger Technology

Parallel Dual Pass

Cold Plate Dimensions

56 x 56 x 1.5 mm

Cold Plate Material

Copper

Cold Plate Technology

Micro-Skived Fin

Magnetic Interchangeable Cold Plate Cover

Anodized Aluminum

Tube Length

400 mm

Tube Material

CIIR Rubber with Nylon Sleeving

Total CPU Block + LCD Screen Height

105 mm

Fans

THICC FP12 x 2

Fan Dimensions

120 x 120 x 32 mm

Fan Speed

0 – 3,000 RPM

Air Flow

105.8 CFM

Static Pressure

8.14 mm-H2O

Noise Level

<10.0* – 47.3 dBA – *Measuring below 10 dBA was not possible in our test chamber due to the noise floor

Bearings

Fluid Dynamic Bearing

Fan Blade Material

Fiberglass Reinforced Liquid Crystal Polymer (LCP)

Fan Frame Material

Polycarbonate

Fan Connector

Nexus Link Type-M

Nexus-Link Channels

1x Type-C, 1x Type-M

Maximum Devices – Single Channel

18

Maximum Devices – All Channels

34

Maximum Current – Single Channel

8A/12V

Maximum Current – All Channels

15A/12V

Maximum PSU Power Draw

Up to 180W depending on the number of connected Nexus Link devices

LCD Size

5 Inches

LCD Mounting Orientation

Portrait Only

LCD Resolution

720 x 1280 (293 PPI)

LCD Panel Type

IPS

LCD Hinge

Double-Hinged Floating Spout

LCD Refresh Rate

60 Hz

LCD Brightness

300 nits

Bias Lighting

42-Pixel qRGB Array

Logo Lighting

4-Pixel qRGB Array

Pump RPM

2,000 – 4,500 RPM

Pump Bearing

Ceramic

Pump Impeller Diameter

24 mm

Coolant Operation Temperatures

-10 to 60 C

Processor

Quad-Core 64-bit ARM Cortex

Speed

1.3 GHz

RAM

2GB DDR4 @2666 MT/s

Storage

32GB eMMC

Graphics Engine

500 MHz
