₨110,497.00
| NUC Kit with 11th Generation Intel® Core™ Processors | NUC Kit with 11th Generation Intel® Core™ Processors | NUC Kit with 11th Generation Intel® Core™ Processors | NUC Kit with 11th Generation Intel® Core™ Processors | NUC Kit with 11th Generation Intel® Core™ Processors | NUC Kit with 11th Generation Intel® Core™ Processors | NUC Kit with 11th Generation Intel® Core™ Processors | |
| Processor Included | Intel® Core™ i3-1115G4 Processor (6M Cache | up to 4.10 GHz) | Intel® Core™ i3-1115G4 Processor (6M Cache | up to 4.10 GHz) | Intel® Core™ i5-1135G7 Processor (8M Cache | up to 4.20 GHz) | Intel® Core™ i5-1135G7 Processor (8M Cache | up to 4.20 GHz) | Intel® Core™ i5-1145G7 Processor (8M Cache | up to 4.40 GHz | with IPU) | Intel® Core™ i7-1165G7 Processor (12M Cache | up to 4.70 GHz) | Intel® Core™ i7-1165G7 Processor (12M Cache | up to 4.70 GHz) |
|---|---|---|---|---|---|---|---|
| Board Number | NUC11TNBi30Z | NUC11TNBi30Z | NUC11TNBi50Z | NUC11TNBi50Z | NUC11TNBv50Z | NUC11TNBi70Z | NUC11TNBi70Z |
| Supported Operating Systems | Windows 11 Home* | Windows 11 Pro* | Windows 10 Home | 64-bit* | Windows 10 IoT Enterprise* | Windows 10 Pro | 64-bit* | Red Hat Linux* | Ubuntu 20.04 LTS* | Windows 11 Home* | Windows 11 Pro* | Windows 10 Home | 64-bit* | Windows 10 IoT Enterprise* | Windows 10 Pro | 64-bit* | Red Hat Linux* | Ubuntu 20.04 LTS* | Windows 11 Home* | Windows 11 Pro* | Windows 10 Home | 64-bit* | Windows 10 IoT Enterprise* | Windows 10 Pro | 64-bit* | Red Hat Linux* | Ubuntu 20.04 LTS* | Windows 11 Home* | Windows 11 Pro* | Windows 10 Home | 64-bit* | Windows 10 IoT Enterprise* | Windows 10 Pro | 64-bit* | Red Hat Linux* | Ubuntu 20.04 LTS* | Windows 11 Home* | Windows 11 Pro* | Windows 10 Home | 64-bit* | Windows 10 IoT Enterprise* | Windows 10 Pro | 64-bit* | Red Hat Linux* | Ubuntu 20.04 LTS* | Windows 11 Home* | Windows 11 Pro* | Windows 10 Home | 64-bit* | Windows 10 IoT Enterprise* | Windows 10 Pro | 64-bit* | Red Hat Linux* | Ubuntu 20.04 LTS* | Windows 11 Home* | Windows 11 Pro* | Windows 10 Home | 64-bit* | Windows 10 IoT Enterprise* | Windows 10 Pro | 64-bit* | Red Hat Linux* | Ubuntu 20.04 LTS* |
| Marketing Status | Launched | Launched | Launched | Launched | Launched | Launched | Launched |
| Launch Date | Q1’22 | Q1’22 | Q1’22 | Q1’22 | Q1’22 | Q1’22 | Q1’22 |
| CPU Total Cores | 2 | 2 | 4 | 4 | 4 | 4 | 4 |
| CPU Total Threads | 4 | 4 | 8 | 8 | 8 | 8 | 8 |
| Max Turbo Frequency | 4.10 GHz | 4.10 GHz | 4.20 GHz | 4.20 GHz | 4.40 GHz | 4.70 GHz | 4.70 GHz |
| # of Memory Slots | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Memory Types | DDR4-3200 1.2V SO-DIMMs | DDR4-3200 1.2V SO-DIMMs | DDR4-3200 1.2V SO-DIMMs | DDR4-3200 1.2V SO-DIMMs | DDR4-3200 1.2V SO-DIMMs | DDR4-3200 1.2V SO-DIMMs | DDR4-3200 1.2V SO-DIMMs |
| Max # of Memory Channels | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| ECC Memory Supported* | No | No | No | No | No | No | No |
| Internal Drive Form Factor | M.2 SSD | M.2 SSD | M.2 SSD | M.2 SSD | |||
| # of Internal Drives Supported | 2 | 3 | 2 | 3 | 2 | 2 | 3 |
| M.2 Card Slot (storage) | 22×80 NVMe (M); 22×42 SATA (B) | 22×80 NVMe (M); 22×42 SATA (B) | 22×80 NVMe (M); 22×42 SATA (B) | 22×80 NVMe (M); 22×42 SATA (B) | 22×80 NVMe (M); 22×42 SATA (B) | 22×80 NVMe (M); 22×42 SATA (B) | 22×80 NVMe (M); 22×42 SATA (B) |
| Graphics Output | Dual HDMI 2.0b w/HDMI CEC | Dual HDMI 2.0b w/HDMI CEC | Dual HDMI 2.0b w/HDMI CEC | Dual HDMI 2.0b w/HDMI CEC | Dual HDMI 2.0b w/HDMI CEC | Dual HDMI 2.0b w/HDMI CEC | Dual HDMI 2.0b w/HDMI CEC |
| # of Displays Supported * | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| # of USB Ports | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| USB Configuration | Front: 2x USB 3.2 Rear: 1x USB 3.2 | 1x USB 2.0 Internal: 1x USB 3.2 on m.2 22×42 (pins) | 2x USB 2.0 (headers) | Front: 2x USB 3.2 Rear: 1x USB 3.2 | 1x USB 2.0 Internal: 1x USB 3.2 on m.2 22×42 (pins) | 2x USB 2.0 (headers) | Front: 2x USB 3.2 Rear: 1x USB 3.2 | 1x USB 2.0 Internal: 1x USB 3.2 on m.2 22×42 (pins) | 2x USB 2.0 (headers) | Front: 2x USB 3.2 Rear: 1x USB 3.2 | 1x USB 2.0 Internal: 1x USB 3.2 on m.2 22×42 (pins) | 2x USB 2.0 (headers) | Front: 2x USB 3.2 Rear: 1x USB 3.2 | 1x USB 2.0 Internal: 1x USB 3.2 on m.2 22×42 (pins) | 2x USB 2.0 (headers) | Front: 2x USB 3.2 Rear: 1x USB 3.2 | 1x USB 2.0 Internal: 1x USB 3.2 on m.2 22×42 (pins) | 2x USB 2.0 (headers) | Front: 2x USB 3.2 Rear: 1x USB 3.2 | 1x USB 2.0 Internal: 1x USB 3.2 on m.2 22×42 (pins) | 2x USB 2.0 (headers) |
| Serial Port via Internal Header | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Integrated LAN | Intel® Ethernet Controller i225-LM | Intel® Ethernet Controller i225-LM | Intel® Ethernet Controller i225-LM | Intel® Ethernet Controller i225-LM | Intel® Ethernet Controller i225-LM | Intel® Ethernet Controller i225-LM | Intel® Ethernet Controller i225-LM |
| Wireless Included | Intel® Wi-Fi 6 AX201 (Gig+) | Intel® Wi-Fi 6 AX201 (Gig+) | Intel® Wi-Fi 6 AX201 (Gig+) | Intel® Wi-Fi 6 AX201 (Gig+) | Intel® Wi-Fi 6 AX201 (Gig+) | Intel® Wi-Fi 6 AX201 (Gig+) | Intel® Wi-Fi 6 AX201 (Gig+) |
| Bluetooth Version | 5.2 | 5.2 | 5.2 | 5.2 | 5.2 | 5.2 | 5.2 |
| M.2 Card Slot (wireless) | 22×30 (E) | 22×30 (E) | 22×30 (E) | 22×30 (E) | 22×30 (E) | 22×30 (E) | 22×30 (E) |
| Additional Headers | Front_panel (PWR | RST | 5V | 5Vsby | 3.3Vsby); Internal 2×2 power connector | Front_panel (PWR | RST | 5V | 5Vsby | 3.3Vsby); Internal 2×2 power connector | Front_panel (PWR | RST | 5V | 5Vsby | 3.3Vsby); Internal 2×2 power connector | Front_panel (PWR | RST | 5V | 5Vsby | 3.3Vsby); Internal 2×2 power connector | Front_panel (PWR | RST | 5V | 5Vsby | 3.3Vsby); Internal 2×2 power connector | Front_panel (PWR | RST | 5V | 5Vsby | 3.3Vsby); Internal 2×2 power connector | Front_panel (PWR | RST | 5V | 5Vsby | 3.3Vsby); Internal 2×2 power connector |
| Total # of SATA Ports | 1 | 1 | 1 | ||||
| Expansion Options PCIE Revision | Gen 4 (m.2 22×80 slot); Gen 3 (otherwise) | Gen 4 (m.2 22×80 slot); Gen 3 (otherwise) | Gen 4 (m.2 22×80 slot); Gen 3 (otherwise) | Gen 4 (m.2 22×80 slot); Gen 3 (otherwise) | Gen 4 (m.2 22×80 slot); Gen 3 (otherwise) | Gen 4 (m.2 22×80 slot); Gen 3 (otherwise) | Gen 4 (m.2 22×80 slot); Gen 3 (otherwise) |
| Expansion Options PCIE Configurations * | PCIe x4 Gen 4: M.2 22×80 (key M) PCIe x1 Gen 3: M.2 22×42 (key B) PCIe x1: M.2 22×30 (key E) | PCIe x4 Gen 4: M.2 22×80 (key M) PCIe x1 Gen 3: M.2 22×42 (key B) PCIe x1: M.2 22×30 (key E) | PCIe x4 Gen 4: M.2 22×80 (key M) PCIe x1 Gen 3: M.2 22×42 (key B) PCIe x1: M.2 22×30 (key E) | PCIe x4 Gen 4: M.2 22×80 (key M) PCIe x1 Gen 3: M.2 22×42 (key B) PCIe x1: M.2 22×30 (key E) | PCIe x4 Gen 4: M.2 22×80 (key M) PCIe x1 Gen 3: M.2 22×42 (key B) PCIe x1: M.2 22×30 (key E) | PCIe x4 Gen 4: M.2 22×80 (key M) PCIe x1 Gen 3: M.2 22×42 (key B) PCIe x1: M.2 22×30 (key E) | PCIe x4 Gen 4: M.2 22×80 (key M) PCIe x1 Gen 3: M.2 22×42 (key B) PCIe x1: M.2 22×30 (key E) |
| Thermal Design Power | 15 W | 15 W | 28 W | 28 W | 28 W | 28 W | 28 W |
| DC Input Voltage Supported | 12-20 VDC | 12-20 VDC | 12-20 VDC | 12-20 VDC | 12-20 VDC | 12-20 VDC | 12-20 VDC |
| Chassis Dimensions | 117 x 112 x 37 [mm] (LxWxH) | 117 x 112 x 54 [mm] (LxWxH) | 117 x 112 x 37 [mm] (LxWxH) | 117 x 112 x 54 [mm] (LxWxH) | 117 x 112 x 37 [mm] (LxWxH) | 117 x 112 x 37 [mm] (LxWxH) | 117 x 112 x 54 [mm] (LxWxH) |
| Board Form Factor | UCFF (4″ x 4″) | UCFF (4″ x 4″) | UCFF (4″ x 4″) | UCFF (4″ x 4″) | UCFF (4″ x 4″) | UCFF (4″ x 4″) | UCFF (4″ x 4″) |
| Intel® Optane™ Memory Supported * | No | No | No | No | No | No | No |
| Intel® Virtualization Technology for Directed I/O (VT-d) * | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Intel® Virtualization Technology (VT-x) * | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Intel® Platform Trust Technology (Intel® PTT) | Yes | Yes | Yes | Yes | Yes | Yes | |
| Intel® ME Firmware Version | 15 | 15 | 15 | 15 | 15 | 15 | 15 |
| Intel® AES New Instructions | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Intel vPro® Eligibility * | Intel vPro® Platform | ||||||
| Intel® Trusted Execution Technology * |
