IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6

AX1800 ultimate AX performance : 1201 Mbps+ 574 Mbps

802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 4 (802.11n) : up to 300 Mbps
WiFi 5 (802.11ac) : up to 867 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps

External antenna x 4

2.4GHz 2×2
5GHz 2×2

1.3GHz dual-core processor

128 MB Flash
256 MB RAM

OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80 MHz bandwidth

2.4GHz / 5GHz

Access Point, AiMesh Node, Repeater, Router

RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 3

WPS Button, Reset Button, Power Switch

Power x 1
WAN x 1
LAN x 3
2.4G x 1
5G x 1
WPS x 1

AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 1 A current

．RT-AX52
．RJ45 Ethernet Cable
．Power Adapter
．Quick Start Guide
．Warranty Card

298g

192 x 126.3 x 47.5 mm (WxDxH)

AiMesh
• Primary AiMesh Router
• AiMesh Node

“Allow you to block access to unwanted websites and apps.”
Customized Internet Schedule

“The Guest Network provides Internet connection for guests but restricts access to your local network.”

Open system, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
WPS
SSH
Firewall

Instant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP

• Bandwidth Limiter
Traditional QoS
Traffic Monitor
• Real-time Traffic Monitor
• Wired Traffic Monitor
• Wireless Traffic Monitor

Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN
Port triggering
DMZ
DDNS

DHCP Server
IGMP Snooping
IPTV
Manually Assign IP Address
Wake on LAN (WOL)

UTF-8 SSID
WiFi MAC Address Filter
Wireless Scheduler
Airtime Fairness
RADIUS Client
Universal Beamforming
Explicit Beamforming

Configuration Backup and Restore
Diagnosis tools
Feedback System
System Log
