Description

Dimensions (L x W x H)

• 140 x 150 x 86  mm

Cybenetics Rating

• 850W: PLATINUM
• 750W/650W: GOLD

80 Plus Rating

• GOLD

ATX Version

• 850W /750W : ATX 12V 3.0
• 650W : ATX 12V 2.4

Protections

• OVP / OPP / SCP / OCP / UVP / OTP / NLO / SIP

Certification

• CB/TUV/cTUVus/CE+UKCA/FCC+IC/LVD+UKCA/BSMI/RCM/BIS/EAC+ROHS/S-MARK/NOM

PFC

• >0.99

Input Voltage

• 100V-240V

Input Current

• 850W : 12A
• 750W : 10A
• 650W :10A

Input Frequency

• 47 – 63 Hz

DC Output Voltage

• +5V | +3.3V | +12V | -12V | +5Vsb

Total Output

• 850W /750W /650W

Power Excursion

• 850W: 1700W (*up to 200% of the PSU’s rated power for 100μs)
• 750W: 1500W (*up to 200% of the PSU’s rated power for 100μs)
• 650W: 1300W (*up to 200% of the PSU’s rated power for 100μs)

Operating Temperature

• 40 °C

Fan Size

• 120 x 120 x 25mm

Fan Bearing

• FDB

Fan Speed

• 2400

MTBF

• 100,000 hours

ATX 24 Pin Connector

• 1

EPS 8 Pin Connector

• 2

PCI-E 6+2 Pin Connector

• 850W : 2
• 750W : 2
• 650W : 2

Molex 4 Pin Connector

• 850W : 2
• 750W : 2
• 650W : 2

12VHPWR (12 + 4) Connector (600W)

• 850W : 1
• 750W : 1
• 650W : 0

SATA Connector

• 850W : 6
• 750W : 6
• 650W : 6

Weight

• 850W : 2.032Kg
• 750W :2.024Kg
• 650W :1.768Kg
