Description

Dimensions (L x W x H)

• 650W-850W: 140 x 150 x 86mm
• 1000W-1200W: 160 x 150 x 86mm

80 Plus Rating

• GOLD

ATX Version

• ATX 12V v3.0 and EPS v2.92

Protections

• OCP | OVP | OPP | OTP | UVP | SCP | NLO | SIP

Certification

• CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Mark | NOM | BSMI | UKCA | EAC | CCC | RCM

PFC

• > 0.99

Input Voltage

• 100-240V

Input Current

• 1200W: 15A
• 1000W: 13A
• 850W: 12A
• 750W: 10A
• 650W: 10A

Input Frequency

• 650/750/850W:47Hz-63Hz
• 1000/1200W:50Hz-60Hz

DC Output Voltage

• +5V | +3.3V | +12V | -12V | +5Vsb

Total Output

• 1200W: +5V/+3.3V :22A, +12V:100A, -12V:0.3A, +5Vsb:3A
• 1000W: +5V/+3.3V :22A, +12V:83.5A, -12V:0.3A, +5Vsb:3A
• 850W: +5V/+3.3V :22A, +12V:70.8A, -12V:0.3A, +5Vsb:3A
• 750W: +5V/+3.3V :22A, +12V:62.5A, -12V:0.3A, +5Vsb:3A
• 650W: +5V/+3.3V :20A, +12V:54.1A, -12V:0.3A, +5Vsb:3A

Power Excursion

• 1200W: 2820W(*up to 235% of the PSU’s rated power for 100μs)
• 1000W: 2350W(*up to 235% of the PSU’s rated power for 100μs)
• 850W: 1997W (*up to 235% of the PSU’s rated power for 100μs)
• 750W: 1762W (*up to 235% of the PSU’s rated power for 100μs)
• 650W: 1527W(*up to 235% of the PSU’s rated power for 100μs)

Operating Temperature

• 50°C

Fan Size

• 650W-850W: 120mm FDB Fan
• 1000W-1200W: 135mm FDB Fan

Fan Bearing

• FDB (Fluid Dynamic Bearing)

Fan Speed

• 2400 RPM

MTBF

• 100K hours at full load

ATX 24 Pin Connector

• 1200W/1000W:1
• 850W/750W/650W:1

EPS 8 Pin Connector

• 1200W/1000W:2
• 850W/750W/650W:2

PCI-E 6+2 Pin Connector

• 1200W/1000W:8
• 850W/750W:6
• 650W:4

Molex 4 Pin Connector

• 1200W/1000W:3
• 850W/750W/650W:4

12VHPWR (12 + 4) Connector (600W)

• 1200W/1000W:1
• 850W/750W/650W:1

SATA Connector

• 1200W/1000W:9
• 850W/750W/650W:8

Weight

• 1200W/1000W:
  Product+cables：1.77kg+1.28kg
  with Package:3.43kg
• 850W/750W:
  Product+cables：1596g+1254g
  with Package:3.1kg
• 650W:
  Product+cables：1299g+1231g
  with Package:2.78kg
